AcerAltos City650 UPS for Computer

Model Name City650
Capacity 650VA/360W
PF 0,6
Nominal Voltage 220-240VAC
Voltage Range 140~300Vac
Frequency Range 50/60Hz （Auto Sensing）
Output voltage 220-240VAC
Boost Ratio 1.2/1.4
Buck Ratio 0,85
Output Voltage Range(batt.mode) ±10%
Frequency Range(batt.mode) 50/60Hz +/- 1%
Transfer time 4ms Typical
waveform (batt.mode) Simulated Sine-wave
Outlet Type UN(2)
Full Protection Overload, Short Circuit, Over discharge and Over charge.
Line mode overload >(110%±10)% fault after alarm 1min
>(120%±10)% fault immediately
Battery mode overload >(110%±10)% fault after alarm 1min
>(120%±10)% fault immediately
Battery Voltage 12V
Battery type&number(CB) 12V 7AH x 1
Typical Backup Time(Based one PC) 22mins @ 1 PC Load With 15 moniter
Typical Recharge Time 8hours to 90% of capability
Display LED
Alarm Battery mode: Sounding every 30 seconds
Low battery: Sounding every 2 seconds
Over load: Sounding every 0.5 seconds
Fault: Continuous sounding
Dimension(W * H * D)(mm) 96*138*286
Net Weight (kgs) 4,3
Temperature & Humidity 0 to +40, 0 to 90% Relative
Humidity (Non-condensing)
Noise Level Less than 40dB
